13. Hold the Pulse Bar (85) near the console assem-

bly (F). Connect the two pulse wires (H), and

connect the Console Ground Wire (58) to the

ground wire (I) from the console assembly (F).

Attach the Pulse Bar (85) to the Pulse Crossbar

(93) with eleven #8 x 1/2" Screws (1); start all

eleven Screws, and then tighten them. Make

sure that no wires are pinched.

12. Slide the Right and Left Handrail Grips (74, 79)

over the Right and Left Handrail Covers (not

shown) and against the console assembly (F).

Attach the Handrail Grips (74, 79) with two

#8 x 1/2" Screws (1); do not overtighten the

Screws.
