CHV190 series special inverter for crane
- 198 -
Function
Code
Name Description
Setting
Range
Factory
Setting
Modify
P1.24
Forced
deceleration time
0.0~3600.0s 0.0~3600.0
2.0s ◎
P1.25 Stop mode
0: Deceleration to stop
1: Coast to stop
0~1 0 ○
P1.26
Subsidiary motor
acceleration time
0.0~3600.0s 0.0~3600.0
1.0s ○
P1.27
Subsidiary motor
deceleration time
0.0~3600.0s 0.0~3600.0
1.0s ○
P1.28 Reserved 0~65535 0~65535 0 ◎
P1.29 Reserved 0~65535 0~65535 0 ◎
P2 Group: Motor parameters
P2.00 Inverter model
0: Asynchronous
machine
1: Synchronous machine
0~1 0 ◎
P2.01 Motor rated power
0.4~900.0kW 0.4~900.0
Depend
on model
◎
P2.02
Motor rated
frequency
0.01Hz~P0.03 0.01~P0.03
50.00Hz
◎
P2.03 Motor rated speed
1~36000rpm 1~36000 1460rpm
◎
P2.04
Motor rated
voltage
0~500V 0~500 380V ◎
P2.05
Motor rated
current
0.1~2000.0A 0.1~2000.0
Depend
on model
◎
P2.06 Motor power factor 0.05~1.00 0.05~1.00
0.86 ◎
P2.07
Motor stator
resistance
0.001~65.535Ω
0.001~
65.535
Depend
on model
○
P2.08
Motor rotor
resistance
0.001~65.535Ω
0.001~
65.535
Depend
on model
○
P2.09
Motor leakage
inductance
0.1~6553.5mH 0.1~6553.5
Depend
on model
○
P2.10
Motor mutual
inductance
0.1~6553.5mH 0.1~6553.5
Depend
on model
○
