CHV190 series special inverter for crane
- 203 -
Function
Code
Name Description
Setting
Range
Factory
Setting
Modify
detection time
P4.06
Position calculator
conversion factor
10.0~6553.5 10.0~6553.5
10.0 ◎
P4.07 Reserved 0~65535 0~65535 0 ◎
P4.08 Reserved 0~65535 0~65535 0 ◎
P5 Group: Input terminals
P5.00 HDI selection
0: HDI high speed pulse
input.
1: HDI switch input.
0~1 0 ◎
P5.01
S4, S5 Input type
selection
0: ON/OFF
1: Master-
slave
synchronization counter
0~1 0 ◎
P5.02
S1 terminal
function
0~40 1 ◎
P5.03
S2 terminal
function
0~40 2 ◎
P5.04
S3 terminal
function
0~40 6 ◎
P5.05
S4 terminal
function
0~40 0 ◎
P5.06
S5 terminal
function
0~40 0 ◎
P5.07
HDI1 terminal
function
0~40 0 ◎
P5.08
S7 terminal
function
0~40 0 ◎
P5.09
S8 terminal
function
0~40 0 ◎
P5.10
S9 terminal
function
0~40 0 ◎
P5.11
S10 terminal
function
0: Invalid
1: Forward
2: Reverse
3: Jog running
4: Low-
speed running
signal
5: Coast to stop
6: Reset fault
7: External fault input
8: Multi-
step speed
terminal 1 (MS1)
9: Multi-
step speed
terminal 2 (MS2)
10: Multi-
step speed
terminal3 (MS3)
11: Contactor feedback
signal (TB)
12:
Brake feedback
signal (FB)
13: Inverter enable
(ENA)
0~40 0 ◎
