006E 6000543 Tie-rod M14x1286
007 6000609 Stud M8x34
008 6105710 Combustion chamber door insulat
009 6105801 Combustion chamber door
010 6037601 Window
011 2050000 Spring TDM
012 6000608 Stud M12x40
013 2030208 Piracriten gasket Ø 65x95x2
014 6105102 Blank flange F.12/T
015 6046700 Flange holding drain cock
016 6020701 Drain cock 3/4"
017 6182005 Casing lower hub panel
018 6000606 Stud M12x50
019 6000612 Stud M12x60
020A 6106200 Water distributor
021 6192400 Flange 2"
022 5004200 Bulb holder 1/2" L=190
023E 5096707 Smoke chamber/down draught-dive
024 1232400 Sealing rope Ø 15
025E 6104827 Burner manifold
026 6023100 Pressure test nipple Ø 1/8"
027 6022003 Aluminium washer Ø 14
028 6105001 Nozzle Ø 4,30 M14 MET
028A 6105003 Nozzle Ø 2,50 M14 GPL
029 6095100 Burner bar type 109/10 L=561
030 6106807 Pipe extension L=60
031 6002707 Junction box
032 6266401 Plastic plug
033E 6105557 Frame, front and rear part
034 6105301 Frame, right hand side part
035 6105401 Frame, left hand side part
036 2003000 Pin M5 Zn
037 6181605 Casing L.H. side rear upper pan
038 6181505 Casing R.H. side rear upper pan
039E 6122695 Casing lower inner panel
040E 6122795 Casing upper inner panel
041E 6122816 Casing rear panel
042 6123052 Casing side front panel
043 2040202 Nipple 1 1/2"
044E 6296255 Casing front lower panel
045E 6296355 Casing front central panel
046E 6296655 Casing front upper panel
047E 6301065 Casing top cover
048 2040002 Union elbow F.F. 1-1/2"
049 2040704 Union 1-1/2" MF
050A 6083403 Pipe reducer 1-1/4"
051 6107401 Gas valve
052 6291688 Gas pressure regulator
053 6043102 Gas pressure switch
054 6107402 By-pass gas valve
055 6221613 Ignition electrode c/w resistan
056 6221605 Ionisation electrode
057 6000623 Stud M5x15 Zn
059 6186515 Ionisation electrode cable
060 6182105 Casing pilot burner panel
061 6222600 Combustion chamber fixing plate
062 6211011 Control panel
063 6181905 Casing upper hub panel
064 6181805 Casing L.H. side rear lower pan
066 6266901 Anti-jamming filter
067 6105158 Flange
068 6105157 Flange + filter
069 2213202 Space Ø 10 for control box
070 6178822 Control box BRAHMA SM 191.2
073 6181705 Casing R.H. side rear lower pan
074 6001400 H.L. stat 100°C
075 6159300 Adjustable boiler stat TRZ
076 6044041 Red gem Ø 10
077 6013501 Switch with warning light
078 6240103 Handle Ø 35
079 6146003 Thermometer 0-120°C
080 6253211 Control panel cover
081 6044016 Signal lamp
083 6202116 5 pole socket with cable
084 6202115 7 pole socket with cable
085 6202113 7 pole plug with cable
086 6202114 5 pole plug with cable
