English | 27

Bosch Power Tools 1 609 929 U65 | (4.11.09)

f Use only original Bosch batteries with the

voltage listed on the nameplate of your

power tool. When using other batteries, e. g.

imitations, reconditioned batteries or other

brands, there is danger of injury as well as

property damage through exploding batter-

ies.

Functional Description

Read all safety warnings and all in-

structions. Failure to follow the

warnings and instructions may re-

sult in electric shock, fire and/or se-

rious injury.

While reading the operating instructions, unfold

the graphics page for the machine and leave it

open.

Intended Use

The machine is intended for cutting, roughing,

and brushing metal and stone materials without

using water.

For cutting metal, a special protection guard for

cutting (accessory) must be used.

For cutting stone, a special extraction hood for

cutting with cutting guide (accessory) must be

used.

With approved sanding tools, the machine can

be used for sanding with sanding discs.

Product Features

The numbering of the product features refers to

the illustration of the machine on the graphics

page.

1 Spindle lock button

2 On/Off switch

3 Allen key

4 Battery*

5 Battery unlocking button

6 Auxiliary handle (insulated gripping surface)

7 Grinder spindle

8 Locking screw for protection guard

9 Protection guard for grinding

10 Mounting flange with O-ring

11 Grinding disc*

12 Clamping nut

13 Quick-clamping nut *

14 Carbide grinding head*

15 Protection guard for cutting*

16 Cutting disc*

17 Hand guard*

18 Rubber sanding plate*

19 Sanding sheet*

20 Round nut*

21 Cup brush*

22 Button for charge-control indicator*

23 Battery charge-control indicator*

24 Handle (insulated gripping surface)

25 Cutting guide with dust extraction

protection guard*

26 Diamond cutting disc*

*Accessories shown or described are not part of the

standard delivery scope of the product. A complete

overview of accessories can be found in our acces-

sories program.

Technical Data

Angle Grinder GWS 18 V-LI

Professional

Article number

3 601 J3A 3..

Rated voltage

V= 18

Rated speed

min

-1

10000

Grinding disc diameter,

max.

mm 115

Thread of grinder

spindle

M 14

Thread length (max.)

of grinder spindle

mm 22

Weight according

to EPTA-Procedure

01/2003

kg 2.3

Please observe the article number on the type plate

of your machine. The trade names of the individual ma-

chines may vary.
