6 English

FUEL

1. Remove the fuel tank cap and check fuel lever. If necessary add some

fuel.

2. Use only motor gasoline (with a minimum of 92 octane or unleaded or

low leaded gasoline).

Never use mixture of oil-fuel or sour gasoline. Avoid getting dirt or water

in the fuel tank.

STARTING ENGINE

1. Close the air shutter. Turn the choke valve switch to the START position.

Attention: If the engine is very hot or the temperature is high, do not close

the choke valve.

2. Start the engine: turn the engine switch to the I position, slowly pull the

handle until there is sensation of resistance, and then pull quickly and

strongly.

Attention: Don’t loosen the handle suddenly in order to avoid rebounding

and hitting the engine. You should replace it along the direction of resil-

ience force of starting. Place the air shutter into the WORK position after

the engine warm-up.

OPERATION

Caution: Ground drill is designed for the operation with 1 (density

600...1600 kg/m3) and 2 ( density 1600... 1900 kg/m3) classes of soil. Con-

tinuous working time of the ground drill with 1 class of soil (sand, clay sand,

vegetable soil, peat) doesn’t exceed 5 min. Continuous working time of the

ground drill with 2 class of soil (light loam, sand with crushed stone) is no

more than 3 min. Recommended interval between continuous usage is no

less than 15 min with full stoppage of the engine. It’s forbidden to decline

the ground drill from the axis of drilling more than 3°. Excessive deviation

can lead to the breakage of the gear case parts.

Never try to drill the hole on full depth of the auger bit. Drill step-by-step.

Oil filler cap /

dipstick

Sealing washer

Drain bolt

Oil filler cap /

dipstick
