- 4 -
(EN)
INSTRUCTION MANUAL
WARNING: BEFORE USING THE BATTERY
CHARGER READ THE INSTRUCTION MANUAL
CAREFULLY.
1. GENERAL SAFETY RULES WHEN USING
THIS BATTERY CHARGER
- During the charge the battery produces
explosive gases, avoid the formation of ames
and sparkes. DO NOT SMOKE.
- Position the batteries to be charged in a well-
ventilated place.
- Inexperience and untrained people should
be properly instructed before using the
appliance.
- This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
- Children shall not play with the appliance.
- Cleaning and user maintenance shall not
be made by children without supervision.
- Disconnect the mains cable before
connecting to or disconnecting the charging
cables from the battery.
- Do not connect or disconnect the clamps to
or from the battery with the battery charger
operating.
- Never use the battery charger inside the car or
in the bonnet.
- Substitute the mains cable only with an
original one.
- If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualied persons in order to
avoid a hazard.
- Do not use the battery charger to charge
batteries which are not rechargeable.
- Make sure the available power supply voltage
corresponds to that shown on the battery
charger rating plate.
- To avoid damaging the vehicle’s electronics,
read, keep and take very careful note of
the information supplied by the vehicle
manufacturer, when using the battery
charger either for charging or starting; the
same applies to the instructions supplied by
the battery manufacturer.
- This battery charger has components such as
switches and relays which can cause arcs or
sparks. Therefore when using it in a garage or
in a similar place set the battery charger in a
suitable case.
- Repair or maintenance of the inside of the
battery charger can be executed only by
skilled technicians.
-
ALWAYS DISCONNECT THE POWER
SUPPLY CABLE FROM THE MAINS
BEFORE ANY MAINTENANCE
INTERVENTION ON THE BATTERY
CHARGER.
2. INTRODUCTION AND GENERAL
DESCRIPTION
- This battery charger is used to charge
electrolyte free lead batteries, sealed batteries
and lithium batteries used on motor vehicles
(petrol and diesel), motorcycles, boats etc.
- Rechargeable accumulators according to the
output voltage available: 6V lead / 3 cells; 12V
lead / 6 cells; 24V lead / 12 cells; 12V and 24V
lithium.
- This model is a single phase 230V 50/60Hz
battery charger, with constantly electronically
controlled current and voltage.
The charge voltage and current supplied by
the device have a IU or U charge curve.
- Standard features:
- The device allows you to connect dierent
types of output cables for the charging of
batteries:
- cables tted with eyelets (g. B-1);
- cables tted with clamps (g. B-2).
3. DESCRIPTION OF THE BATTERY CHARGER
Control, adjustment and indicator devices.
3.1 LCD version battery charger
Charge voltage.
Using the button in g. A-1 you can set one of
the following functions, charging or test, in
succession:
PULSE TRONIC functions
-
-
-
-
-
-
-
-
-
-
-
-
-
-
TEST functions
-
: Battery Test
-
: Starting Test
-
: Alternator test
-
: Battery Test
-
: Starting Test
-
: Alternator test
In PULSE - TRONIC mode, pressing the key
in g. A-1 for 3 seconds you set one of the
following advanced functions:
-
Supply
-
Recovery
-
Boost
3.1.1 Graphic symbols
Indicates the general alarm: polarity reversal.
The PULSE TRONIC and RECOVERY processes
indicate the process did not have a positive
outcome.
