English (original instructions)
EN
DE ES IT FR PT NL RU FI SV NO DA PL CS SK SL HR HU RO BG EL AR TR HE LT LV ET
MAINTENANCE
WARNING
All service and all maintenance checks must be carried
out on a stationary machine with the motor switched off.
Before any maintenance operation, switch off the mo-
tor.
WARNING
Wear adequate clothing, gloves and goggles before car-
rying out any maintenance.
REPLACING THE SCRAPER (FIG.5 -6)
WARNING
IN ORDER TO AVOID SERIOUS PERSONAL INJURY,
TURN THE SNOW SHOVEL OFF AND UNPLUG IT
BEFORE PERFORMING ANY MAINTENANCE.
Use only the manufacturer's original replacement parts.
Place the snow shovel on the ground or on a work
bench. Position the snow shovel so that the impeller
is facing up.
Remove the four screws (13) that are located beneath
the impeller that secure the scraper to the housing
using a phillips screwdriver.
Remove the scraper (6), and discard it in the proper
manner.
Snap the new scraper into position, and attach it to the
snow shovel by reinstalling the four screws.
REPLACING THE IMPELLOR &'
①.
②.
③.
④.
⑤.
⑥.
⑦.
⑧.
⑨.
Remove the right side cover by removing 6 screws.
Pull the belt tensioner (idler arm) away from the drive
pulley. Be sure not to lose the washer, spring and
screw left.
Remove the belt.
Remove the 4 screws.
Remove the left side cover by removing 6 screws.
Remove the nut that secures the left side plate.
Remove the impellor shaft with pulley assembly
attached.
Withdraw the old/damaged impellor. Be sure not to
loose the shaft sleeve that secures left side of the
shaft.
Insert the impellor shaft with pulley assembly attached
in the new impellor. Be sure to replace the retained
shaft sleeve that secures left side of the shaft.
Replace and tighten the remaining nut to secure the
left side plate assembly.
Replace and tighten the remaining screws to secure
the left side cover.
Replace and tighten the remaining screws to secure
the pulley assembly.
Place the belt back into its place.
Place the belt tensioner (idler arm) back into its place.
Replace and tighten the remaining screws to secure
the right side cover.
⑨.
10
⑨
.
11
⑨
.
12
⑨
.
13
⑨.
14
⑨
.
15
STORAGE
Allow the motor to cool down before storing.
Store the snow shovel in a locked location in order to
prevent unauthorized use or damage.
Store the snow shovel in a dry, well-ventilated area.
Store the snow shovel out of the reach of children.
CLEANING

shovel off and remove battery before cleaning or servic-
ing.
Use a small brush to clean the outside of the snow
shovel. Do not use strong detergents.
Household cleaners that contain aromatic oils such as
pine and lemon, and solvents such as kerosene can
damage the plastic housing and handles. Wipe off any
moisture using a soft cloth.
5
