![DWT STS-750 VP Инструкция по эксплуатации онлайн [5/32] 510054](/views2/1638108/page5/bg5.png)
STS-400 VS STS-500 VS STS-550 VP STS-750 VPSTS-650 VP
400 500 550 750650
0-2800 0-2800 0-2800 700-30000-2800
2,00 2,00 2,10 3,102,10
55 60
65
10080
5 6
8 88
0° - 45° 0° - 45° 0° - 45° 0° - 45°0° - 45°
/ II / II / II / II / II
L ; dB(A)
pA
STS-400 VS
STS-500 VS
STS-550 VP
STS-650 VP
82,00
84,60
84,90
86,90
L ; dB(A)
WA
95,00
97,60
97,90
99,90
6,30
6,30
6,30
6,30
2
m/s
85,00 96,00 5,40
STS-750 VP
Tool specifications
* Optional extra
Noise / Vibration information
Not all of the accessories illustrated or described
· Level of sound pressure, measured according to
are included as standard delivery.
EN 50144.
· Hand/arm weighted vibration value according to
EN 50144.
L - sound pressure (dB(A));
pA
The machine is intended for the sawing of wood, plastic
L - acoustic power (dB(A));
WA
2
and aluminium materials.
- weighted vibration (m/s ).
One to the comprehensive accessory and saw blade
program, the machine can be used for many applications
Always wear ear protection if the sound
and is very well suited for curved or circular cuts.
pressure exceed 85 dB(A).
Operating controls
Optional extra
1 Thumbwheel for stroke rate selection
You can find the recommended DWT accessories on
2 On/Off switch
the page 28 of the instruction. The bright range of the
3 Locking button
accessories will allow you to perform necessary kinds of
4 Dust cover for vacuuming
works effectively.
5 Saw blade *
6 Guide roller
General safety hints for work with
7 Lever for pendulum stroke adjustment (STS-550 VP,
electric tools
STS-650 VP, STS-750 VP)
8 Base plate
· Please, read and take note of the following comments
9 Ventilation slots
that regard your protection against electric shock and
10 Vacuuming connector piece *
risk of injury and fire.
Screw (2 x)
· Verify that the power supply in your area is compatible
12 Wing screw for parallel guide *
with the voltage listed on the machine.
13 Guide bar for parallel cutting / circle cutting *
14
Check the electric tools and electrical connections for
Aligning pin *
·
15 (STS-750 VP)
any damage.
Locking lever
Congratulations!
Dear Customer,
DWT is confident of the quality of its products and offers
an outstanding guarantee. Our aim is to provide quality
tools at an affordable price. We hope that you will enjoy
using this tool for many years.
The DWT team.
Intended use
11
GB
Model
Rated power; W
Weight; kg
Safety class
Stroke rate at no load; SPM
Cutting ability: mm
- In wood
- In aluminium
Bevel cuts (left/right)
Model
5
