Cutting angle adjustment

Dust vacuuming with the external

extractor device

Dust extraction prevents large accumulations

To set the saw for bevel and angled cutting, undo the

of dust, high concentration of dust in the

holding screws 11 of the saw base with the adjusting

ambient air, and facilitates disposal.

wrench and push the base back out of its rest position.

For long periods of working with wood or for

Set the cutting angle by angling the base to the right or

commercial use on materials that produce dust that is

the left. The angles 0°, 15°, 30° and 45° are marked, but

detrimental to health, the machine is to be connected to

values in - between these can be easily set. Firmly

a suitable external dust extraction device.

tighten both holding-screws (fig. 1).

(STS-750 VP)

Pendulum action setting

· Loosen the locking lever 15 by turning it

(STS-550 VP, STS-650 VP, STS-750 VP)

anticlockwise.

· Move the base plate 8 forward; set the desirable

The saw blade pendulum action that is

angle of the base by using markings on a scale.

adjustable in four steps, makes possible the

optimal adaptation of sawing advancing

· Tighten the locking lever 15 by turning it clockwise.

(cutting speed), cutting performance and cut

appearance of the machined material.

Plunge sawing

For each downward movement, the saw blade is lifted

off the material, which facilitates sawdust ejection,

Only soft materials such as wood, aerated

reduces heat generated by friction and increases the

concrete, plaster board, etc. may be

service life of the saw blade. At the same time, the

worked with the plunge method.

reduction of the necessary advancing force provides

fatigue-free working.

Cut-outs in wood are possible without predrilling by

The adjustment lever 7 makes possible the adjustment

piercing with the running machine. This requires a

of the pendulum action in four steps. The switching can

certain amount of practice, however, and is possible

take place with the machine running:

only with short saw blades.

Place the front edge of the base plate on the workpiece

Step 0:

and switch on. Press the machine firmly against the

No pendulum action;

workpiece and plunge the saw blade slowly into the

workpiece.

After reaching the required cutting depth, bring the

Step I:

machine again to the normal working position so that the

Small pendulum action;

complete surface of the base plate rests on the

workpiece and continue to saw along the cutting line.

Step II:

Medium pendulum action;

Step III:

Large pendulum action;

The following basic recommendations are to be

observed:

· the smaller the pendulum step selected (or

switched off), the finer and cleaner the cut edge;

After completing the cut, first switch off the machine and

· when working with thin materials, like metal sheet, the

then pull it out of the cut.

pendulum action should be switched off (step 0);

· materials such as soft wood cut in the direction of the

Circle cutting

grain, the maximum pendulum action can be used.

Guide bar for parallel cutting/ circle cutting 13 and

the aligning pin 14 enable circle cutting with

Operating instruction

required radius (fig. 2).

Sawing

· Mark the circle which will be cut and drill the opening

Do not force the saw; this causes the saw blade to

in its centre.

overheat and bend and/or break. If material to be cut is

· If the cutting does not start from the edge of the

thin, place it on an additional board/plate to dampen

material, drill the opening from which the cutting will

vibrations and improve cutting.

start.

(STS-400 VS, STS-500 VS, STS-550 VP, STS-650 VP)
