Technical information

Explosion drawing and parts list

CE35E (3500100) HAND PLANER CE35E | Version F (From serial number 88145)

Pos. Serial No. Code Description Quantity

44 3502176 LATERAL SLIDE 1

48 3519145 LABEL 1

51 9868221 CAPACITOR 1

52 3524067 BEARING COVER 1

54 3504030 RUBBER PIN 2

55 5323141 WRENCH 8 mm 1

56 2070004 PAN HD. TAPPING SCREW 6X1/4 PH.BZ 2

57 3546021 GUIDE 1

58 3588029 ROLL PIN D.5X16 2

58 90715 3588164 PIN D.5X18 2

59 3502729 NOZZLE 1

60 3546140 CUTTER BLOCK ASS'Y 1

61 3550111 CONNECTION STATOR/SWITCH 2

62 2422166 BLADE SUPPORT SCREW 1

63 3583014 WASHER D.16.51X21.72X0.25 1

64 3568220 FERRITE 2

65 3526152 SPRING 1

66 3523390 BLADES PROTECTOR 1

67 8423195 WASHER D.6.3XD.15X1.5 1

68 4679014 SCREW D.4X10 TX 1

69 3580060 WASHER D.18.5X25X1 1

70 3523414 BELT PROTECTION 1

72 3545497 COVER ASSY 1
