Technical information

Explosion drawing and parts list

AF11 (7100000) 3-PHASE SANDER AF11 | Version D (From serial number 20717)

Pos. Serial No. Code Description Quantity

43 4007020 MOTOR COVER 1

44 3025026 REGULATING KNOB 1

45 3026021 SPRING 1

46 3178016 SCREW M.5X15 PH. 2

47 4001076 COVER 1

48 4020021 SHAFT 1

49 1210001 BALL BEARING 6202 LLB 1

50 1288012 RETAINING RING SW-15 1

51 3001075 SANDER BASE ASS'Y 1

52 4024051 SHOE CUSHION 1

53 4023051 SHOE PLATE 1

54 7178003 SCREW M.5X12 PH. 10

55 3011002 NEADLE BEARING HK 1412 1

56 3024083 ROLLER CAP 1

57 3004012 DRIVING ROLLER 1

58 4021027 HEX. NUT M.12 (LEFT) 1

59 7146065 CORD ASS'Y 1

60 4510013 BALL BEARING 6200-2RS 1

61 4024078 CAP 1

62 3002089 END CAP 1

63 4085015 HEX. NUT M.8 (LEFT) 1

64 1970001 PAN HD. TAPPING SCREW 8X1/2 PH.B. 2

65 2023020 SPRING WASHER E=0.7 1

66 8002043 CORD ARMOR 1

69 4016021 WARNING LABEL 1

70 7170024 SCREW 8X1 PH.B. 2

80 1372016 PAN HD. SCREW M.4X6 PH. 1

81 7168188 TERMINAL 1

82 6689043 BALL D.6.35 1
