Technical information

Explosion drawing and parts list

FP114 (1400100) TRIMMER FOR FITTING HINGES | Version A (From serial number 1000)

Pos. Serial No. Code Description Quantity

1 1425001 KNOB PARALLEL GUIDE M6X12 3

2 1402002 PARALLEL GUIDE 1

3 1402003 PARALLEL GUIDE SUPPORT 1

4 1425004 KNOB ADJUSMENT PARALLEL GUIDE 1

5 2085002 HEX. NUT M.6 2

6 1472006 SCREW 4X16 PH 6

7 1406007 BASE 1

8 1475008 HEX. SOCKET SET SCREW M.6X6 2

9 1422009 GUIDE COLUMN 2

10 1426010 COLUMN SPRING 2

14 1423014 PAWL 1

21 1446905 1

21 1446906 KIT COLLET D.8+NUT 1

27 6710041 BALL BEARING 6002-2RS 1

28 8088020 RETAINING RING D.32 1

29 1451029 ARMATURE 230V 1

30 1417030 CARBON BRUSHES SET 1

31 1445031 BRUSH HOLDER 2

32 1402032 BRUSH HOLDER COVER 2

33 3510009 BALL BEARING 627-Z 1

35 1402035 FAN GUIDE 1

37 1455037 STATOR 230V 1

39 1415039 SWITCH 1

45 1402046 CORD ARMOR 1

46 1446045 CORD 2X1 (EUROPE) 1

47 1973020 FLAT HD. SCREW M.4X10 PH. 2

48 2385005 HEX. NUT M.4 2

53 7722120 GUIDE RING D.8 1

54 7278014 SCREW M.4X8 2

55 2322405 WASHER D.4.2X11X2 2

56 4524082 WRENCH 17 mm 1

57 1440057 CARBIDE STRAIGHT BIT D.14 1

59 1446904 1
