Technical information

Explosion drawing and parts list

FR129VB (2900810) FR129VB (250mm) ROUTER FOR HINGES | Version A (From serial number 190096)

Pos. Serial No. Code Description Quantity

133 2921650 COLUMN 1

135 2933186 STOPPER 1

136 2921651 UPPER STOPPER 1

140 3488090 WASHER 2

141 4303087 STOPPER 2

142 2988181 ROLL PIN D.2.5X8 1

143 2907089 PUSH BUTTON 1

145 2950170 GUIDE RING D.20 1

145 2950171 GUIDE RING D.16 1

145 2950172 GUIDE RING D.15 1

145 2950173 GUIDE RING D.14 1

146 2921645 SHAFT 1

147 2946769 BIT SUPPORT 1

148 1640127 MORTISING BIT D.16 1

148 1640367 MORTISING BIT D.20 1

148 1640379 BIT FOR CONCEALED HINGES D.15 1

148 1640383 BIT FOR CONCEALED HINGES D.14 1

149 2322405 WASHER D.4.2X11X2 2

150 9875082 SCREW M.4x10 K12 2

151 2946765 BIT ASS'Y D.14 FOR CONCEALED HINGES 1

151 2946766 BIT ASS'Y D.20 FOR CONCEALED HINGES 1

151 2946767 BIT ASS'Y D.16 FOR CONCEALED HINGES 1

151 2946768 BIT ASS'Y D.15 FOR CONCEALED HINGES 1

152 2925164 KNOB 1
