4
8. It is possible to damage the instrument and endanger the safety of the users when measuring the
voltage over the range limit. The allowed maximum voltage is printed on the front panel of the
instrument, do not input the range limit specified to avoid the electric shock and instrument
damage.
9. Do not measure any voltage when connecting the test lead with the current terminal to avoid
damaging the instrument and endangering the safety of the users.
10. Do not try to calibrate or repair the instrument, should operate it by the specially trained or
qualified professional people.
11. The function range selection knob should be set in the correct range when measuring.
When switching the function/range selection knob, keep the test lead off the tested object to make
sure there is no any signal at the input terminal. Do not switch the function/range selection knob
when measuring.
12. When LCD display , please replace the battery In time to make sure the measuring
accuracy.
13. Do not allow to measure the voltage when connecting the test lead with the current terminal?
14. Do not try to modify the inner circuit at will to avoid damaging the instrument and endangering
the safety of the users.
4. Safety Symbol Description
Warning
DCA
High Voltage! Dangerous!
ACA
GND
DCA & ACA
Dual Insulation
Meets the direction of European IEC
Low Battery
Fuse
5. Front Panel Description
1. Instrument Model Numb
2. LCD Display
3. HOLD: Date Hold button, press the button, the value is held on
LCD; Press the button again,
exit the hold mode and get in the normal measuring status.
4. Hz/DUTY: Frequency/Duty Circle selection button, press the
button to switch between the Frequency and Duty Circle mode at
Frequency Range; Press the button to switch to Voltage or
Current/Frequency/ Duty Circle mode at AC Voltage or AC Current
Range.
5. SELECT: button switch, press the button to switch the measuring
function.
6. MAX/MIN: Maximum, Minimum, press the button ,
the instrument gets into the MAX mode, the measuring maximum
value will be held at this mode; Press the button again to get into the
