1. SUMMARIZE

The meter is a stable multimeter with 40mm LCD display, driven by battery. It's widely used on

measuring DCV, ACV, DCA, ACA, resistance, capacitance, diode, transistor, continuity test

,temperature auto power off /on and LCD back – light . It’s an ideal tool for lab, factory and family.

2. SAFETY NOTE

The meter meets the standards of IEC1010. Read the operation manual carefully before operation.

1．Do not input limit over-ranged.

2．The voltage below 36V is safety. To avoid electric shock, check whether the test leads are

connected correctly, whether the insulation is good when measuring over 36DCV or 25ACV.

3．Remove the test leads when changing function and range.

4．To select correct function and range, beware of error operation.；

5．Do not operate the meter if battery case and back cover is not fixed.

6．Do not input voltage when measuring resistance.

7．Remove test leads from test point and turn off the power before replacing battery and fuse.

8．SAFETY SYMBOLS

“ ”EXISTS DANGEROUS VOLTAGE，“ ” GND，“ ”DUAL INSULATION

“ ”THE OPERATOR MUST REFER TO THE MANUAL ，“ ”LOW BATTERY

3. CHARACTERISTIC

3.1．

．．

．GENERAL

1-1．Display :LCD displaying.

1-2．Max. displaying: 1999（3 1/2digit）auto polarity indication.

1-3．Measuring method: dual slope A/D conversion.
