2.5. Terminals

• + Terminal receiving the anode

• - Terminal receiving the cathode

Only for measuring the diode and the polar capacitance.

3. TECHNICAL SPECIFICATIONS

3.1. General specifications

• Environment conditions

Pollution degree: 2

Altitiude < 2000m

Operating temperature: 0 ~40°C, (<80%°C or >28°C)

Storage temperature: -10~60°C, (<70%RH, battery removed)

• Temperature Coefficient: 0,1x(specified accuracy)/VC(<18°C or >28°C)

• MAX. Voltage between terminals and earth ground: 50V DC or 36V AC rms

• Sample Rate: 3 times/sec for digital data

• Display: 2 2/3 digits LCD display with max. reading 2999

5 5/6 digits LCD display with max . reading 5999

• Over Range indication: LCD will display “OL”

• Low battery indication: The „ ” is displayed when the battery is under the proper operation

range.

• Auto power off: If there key been operated for 10 minutes, the meter will auto power off to save

battery energy.

• Power source: 3.0 V battery.

• Dimension: 181 (L)x35(W)x20(H)mm

• Weight: 65g. Approx.(battery included)

3.2. Measurement specifications

• Accuracy: ±(% of Reading + number of digits) at 18°C to 28° ( 64°F to 82°F) with relative humidity

to 80%

Caution when working with voltages above 50 V DC or 36V AC rms.

3.2.1. Resistance

Range Resolution Accuracy

300Ω/600Ω 0.1Ω ±(1.2% of rdg + 2 digits)

3kΩ/6kΩ 1Ω

30kΩ/60kΩ 10Ω

300kΩ/600kΩ 100Ω

3MΩ/6MΩ 1kΩ

30MΩ/60MΩ 10kΩ ±(2.0% of rdg + 5 digits)
