8
Note: The temperature probe is fitted with a type K mini connector. A mini connector to banana
connector adaptor is supplied for connection to the input banana jacks.
SPECIFICATIONS
Technical:
Insulation: Class2, Double insulation.
Overvoltage category: CATIV 600V,CATIII 1000V
NOTE: These meters meet CAT III and CAT IV IEC 61010 standards. The IEC 61010 safety standard
defines four overvoltage categories (CAT I to IV) based on the magnitude of danger from transient
impulses. CAT III meters are designed to protect against transients in fixed-equipment installations
at the distribution level; CAT IV meters are designed to protect against transients from the primary
supply level (overhead or underground utility service).
Maximum voltage between any terminal and earth ground: 1000V DC/AC RMS
Surge Protection: 8kV peak IEC 61010
AC True RMS: The term stands for “Root-Mean-Square,” which represents the method of calculation
of the voltage or current value. Average responding multimeters are calibrated to read correctly
only on sine waves and they will read inaccurately on non-sine wave or distorted signals. True rms
meters read accurately on either type of signal.
Display: 4000 counts LCD display, 21mm high
Polarity: Automatic, (-) negative polarity indication.
Over-range: “OL” mark indication.
Low battery indication: A battery “ “ symbol is displayed when the battery
voltage drops below the operating level.
Measurement rate: 2 times per second nominal.
Auto power off: Meter automatically shuts down after approx. 30 minutes of
inactivity.
Operating environment: -10
o
C to 50
o
C (14
o
F to 122
o
F) at < 70 % relative humidity.
Storage temperature: -30
o
C to 60
o
C (-4
o
F to 140
o
F) at < 80 % relative
humidity.to
Relative humidity: 90% (0
o
C to 30
o
C); 75%(30
o
C to 40
o
C); 45%(40
o
C to 50
o
C);
For inside use, max height: Operating:3000m, Storage 10,000m
Pollution degree: 2
Safety: The instrument complies with IEC 61010-1:2001 and IEC,
61010-031:2002
Power: One 9V battery , NEDA 1604, IEC 6F22.
Dimensions: 182 (H) x 82 (W) x55 (D) mm
Weight: Approx.: 375g.
ACCURACY
Accuracy is given at 18
o
C to 28
o
C (65
o
F to 83
o
F), less than 70 % RH
