1587/1577
Users Manual
10
Table 4. Display Indicators (cont.)
Feature Description
Auto Range
ManualRange
610000mV
Display range in use
2500V
1000V
Source voltage rating for insulation
test: 50, 100, 250, 500 (default) or
1000 V on the 1587. 500 (default) and
1000 V ranges available on the 1577.
50 (default) and 100 V on the 1587T.
T Insulation test indicator. Appears when
insulation test voltage is present.
Table 5. Error Messages
Message Description
batt
Appears on the primary display and
indicates that the battery is too low for
reliable operation. The Meter will not
operate at all until the battery is replaced.
The b also appears when batt is on the
primary display.
bat
Appears on the secondary display and
indicates that the battery is too low to
perform an insulation test. The t
button is disabled until the battery is
replaced. This message disappears when
the rotary switch is turned to any other
function.
OPEn
Appears when an open thermocouple is
detected.
LEAd
Test lead alert. The message appears
briefly and a single beep will sound when
you move the switch in or out of the c
position.
15--Err
Model detect error. Service Meter if this is
displayed.
