(6901-002112 <00>)
14
4
Attach TV to Arm
For clarity, TV is not shown.
1. Attach the TV bracket [01] to the arm assembly [03]. There is an
audible click when the parts are correctly assembled.
2. TILT TV UPWARD. Install and tighten locking screw [27].
1
[01]
[03]
Cable Management
1. Pull the arm [03] to its full extension. Remove cable cover (C).
2. Route cables throught the arm. Leave enough slack to prevent
stretching the cables.
3. Rattach cable cover (C).
1
2
3
(C)
[03]
(C)
2
[27]
5
(L)
