Gigabyte GA-AX370-Gaming K3 (rev. 1.0) Инструкция онлайн [7/40] 528606

USB  ASMedia

USB 3.1 Gen 2 Controller:

- 2xUSB3.1Gen2Type-Aports(red)onthebackpanel

 CPU:

- 4 x USB 3.1 Gen 1 ports on the back panel

 Chipset:

- 6 x USB 3.1 Gen 1 ports (2 ports on the back panel, 4 ports available through

theinternalUSBheaders)

- 4 x USB 2.0/1.1 ports available through the internal USB headers

Internal

Connectors

 1 x 24-pin ATX main power connector

 1 x 8-pin ATX 12V power connector

 1 x CPU fan header

 1 x water cooling CPU fan header

 2 x system fan headers

 1 x system fan/water cooling pump header

 2 x SATA Express connectors

 8 x SATA 6Gb/s connectors

 1 x M.2 Socket 3 connector

 1 x front panel header

 1 x front panel audio header

 1xS/PDIFOutheader

 2 x USB 3.1 Gen 1 headers

 2 x USB 2.0/1.1 headers

 1 x serial port header

 1xTrustedPlatformModule(TPM)header

 1 x Clear CMOS jumper

Back Panel

Connectors

 1 x PS/2 keyboard/mouse port

 1xHDMIport

 2xUSB3.1Gen2Type-Aports(red)

 6 x USB 3.1 Gen 1 ports

 1xRJ-45port

 1xopticalS/PDIFOutconnector

 5xaudiojacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In,

LineOut,MicIn)

I/O Controller  iTE

I/O Controller Chip

Hardware

Monitor

 Voltage detection

 Temperature detection

 Fan speed detection

 Overheating warning

 Fan fail warning

 Fan speed control

* Whetherthefan(pump)speedcontrolfunctionissupportedwilldependonthefan

(pump)youinstall.

BIOS  2x128Mbitash

 Use of licensed AMI UEFI BIOS

 SupportforDualBIOS

™

 PnP1.0a,DMI2.7,WfM2.0,SMBIOS2.7,ACPI5.0

- 7 -
