Expansion Slots Integrated in the CPU (PCIEX16/PCIEX8):
3rd Generation AMD Ryzen
™
processors:
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x8 (PCIEX8)
2nd Generation AMD Ryzen
™
processors/3rd Generation AMD Ryzen
™
with
Radeon
™
Graphics processors:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 (PCIEX16)
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 (PCIEX8)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When using the 3rd
Generation AMD Ryzen
™
processors/2nd Generation AMD Ryzen
™
processors/3rd
Generation AMD Ryzen
™
with Radeon
™
Graphics processors, the PCIEX16 slot
operates at up to x8 mode.
2nd Generation AMD Ryzen
™
with Radeon
™
Vega Graphics processors/1st
Generation AMD Ryzen
™
with Radeon
™
Vega Graphics processors:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 (PCIEX16)
Integrated in the Chipset (PCIEX4/PCIEX1):
- 1 x PCI Express x16 slot, supporting PCIe 4.0
(Note 2)
/3.0 and running at x4
(PCIEX4)
- 2 x PCI Express x1 slots, supporting PCIe 4.0
(Note 2)
/3.0
Multi-Graphics
Technology
(Note 3)
Support for NVIDIA
®
Quad-GPU SLI
™
and 2-Way NVIDIA
®
SLI
™
technologies
Support for AMD Quad-GPU CrossFire
™
and 2-Way AMD CrossFire
™
technologies
Storage Interface Integrated in the CPU (M2A_SOCKET):
3rd Generation AMD Ryzen
™
processors:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe 4.0 x4/x2 SSD support)
2nd Generation AMD Ryzen
™
processors/3rd Generation AMD Ryzen
™
with
Radeon
™
Graphics processors/2nd Generation AMD Ryzen
™
with Radeon
™
Vega Graphics processors/1st Generation AMD Ryzen
™
with Radeon
™
Vega
Graphics processors:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe 3.0 x4/x2 SSD support)
Integrated in the Chipset (M2B_SOCKET/M2C_SOCKET):
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe 4.0
(Note 2)
/3.0 x4/x2 SSD support) (M2B_SOCKET)
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe
4.0
(Note 2)
/3.0 x2 SSD support) (M2C_SOCKET)
- 6 x SATA 6Gb/s connectors
- Support for RAID 0, RAID 1, and RAID 10
* Refer to "1-8 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
(Note 2) For 3rd Generation AMD Ryzen
™
processors only.
(Note 3) For 3rd Generation AMD Ryzen
™
processors/2nd Generation AMD Ryzen
™
processors/3rd Generation
AMD Ryzen
™
with Radeon
™
Graphics processors only.
- 8 -
