Storage Interface Chipset:
- 2 x SATA Express connectors
- 8 x SATA 6Gb/s connectors
- SupportforRAID0,RAID1,andRAID10
* Referto"1-8InternalConnectors,"fortheinstallationnoticesfortheM.2andSATA
connectors.
Multi-Graphics
Technology
Support for NVIDIA
®
Quad-GPU SLI
™
and2-WayNVIDIA
®
SLI
™
technologies
Support for AMD Quad-GPU CrossFire
™
and2-WayAMDCrossFire
™
technologies
USB ASMedia
®
USB 3.1 Gen 2 Controller:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
- 1xUSB3.1Gen2Type-Aport(red)onthebackpanel
Chipset:
- 2xUSB3.1Gen2Type-Aports(red)onthebackpanel
- 6 x USB 3.1 Gen 1 ports (2portsonthebackpanel,4portsavailablethrough
theinternalUSBheaders)
- 4xUSB2.0/1.1ports(availablethroughtheinternalUSBheaders)
CPU:
- 4 x USB 3.1 Gen 1 ports on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x U.2 connector
1 x M.2 Socket 3 connector
2 x SATA Express connectors
8 x SATA 6Gb/s connectors
1 x CPU fan header
1 x water cooling CPU fan header
4 x system fan headers
2 x system fan/water cooling pump headers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
2 x USB 3.1 Gen 1 headers
2 x USB 2.0/1.1 headers
1xTrustedPlatformModule(TPM)header
1xCPUcoolerLEDstrip/RGBLEDstripextensioncableheader
1xRGB(RGBW)LEDstripextensioncableheader
2 x temperature sensor headers
1 x Clear CMOS jumper
1 x power button
1 x reset button
1 x Clear CMOS button
1 x OC button
2 x BIOS switches
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x HDMI port
1 x USB Type-C
™
port, with USB 3.1 Gen 2 support
3xUSB3.1Gen2Type-Aports(red)
6 x USB 3.1 Gen 1 ports
2xRJ-45ports
1 x optical S/PDIF Out connector
- 7 -
