Storage Interface  Integrated in the CPU:

- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and

PCIe3.0x4/x2SSDsupport)(M2A_SOCKET)

- 2xSATA6Gb/sconnectors(ASATA31/2)

 Integrated in the Chipset:

- 1xM.2connector(Socket3,Mkey,type2280SATAandPCIe3.0x2SSD

support)(M2B_SOCKET)

- 4xSATA6Gb/sconnectors(SATA30/1/2/3)

 SupportforRAID0,RAID1,andRAID10

* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA

connectors.

USB  Integrated in the CPU:

- 4 x USB 3.1 Gen 1 ports on the back panel

 Integrated in the Chipset:

- 2xUSB3.1Gen2Type-Aports(red)onthebackpanel

- 2 x USB 3.1 Gen 1 ports available through the internal USB headers

- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through

theinternalUSBheaders)

Internal

Connectors

 1 x 24-pin ATX main power connector

 1 x 8-pin ATX 12V power connector

 1 x CPU fan header

 3 x system fan headers

 2 x M.2 Socket 3 connectors

 6 x SATA 6Gb/s connectors

 2xaddressableLEDstripheaders

 2xaddressableLEDstrippowerselectjumpers

 1xCPUcoolerLEDstrip/RGBLEDstripheader

 1xRGB(RGBW)LEDstripheader

 1 x front panel header

 1 x front panel audio header

 1xS/PDIFOutheader

 1 x USB 3.1 Gen 1 header

 2 x USB 2.0/1.1 headers

 1 xTrusted PlatformModule (TPM) header(2x6 pin, forthe GC-TPM2.0_S

moduleonly)

 1 x serial port header

 1 x speaker header

 1 x Clear CMOS jumper

 1 x chassis intrusion header

Back Panel

Connectors

 1 x PS/2 keyboard/mouse port

 2 x USB 2.0/1.1 ports

 1xDVI-Dport

 1xHDMIport

 4 x USB 3.1 Gen 1 ports

 1 x RJ-45 port

 2xUSB3.1Gen2Type-Aports(red)

 6 x audio jacks

- 7 -
