USB Chipset:
- 2 x USB 2.0/1.1 ports available through the internal USB headers
- 5 x USB 3.0/2.0 ports (3 ports on the back panel, 2 ports available through
the internal USB header)
Chipset+Intel
®
USB 3.1 Controller:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 support
- 1 x USB 3.1 Type-A port (red) on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
6 x SATA 6Gb/s connectors
2 x SATA Express connectors
1 x M.2 Socket 3 connector
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x USB 3.0/2.0 header
1 x USB 2.0/1.1 header
1 x S/PDIF Out header
1 x speaker header
1 x Clear CMOS jumper
1 x chassis intrusion header
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x HDMI port
2 SMA antenna connectors
1 x DVI-D port
1 x USB Type-C
™
port, with USB 3.1 support
1 x USB 3.1 Type-A port (red)
3 x USB 3.0/2.0 ports
1 x RJ-45 port
1 x optical S/PDIF Out connector
5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In,
Line Out, Mic In)
I/O Controller iTE
®
I/O Controller Chip
Hardware
Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU/System overheating warning
CPU/System fan fail warning
CPU/System fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
- 8 -
