AudioJackCongurations:

Jack

Headphone/

2-channel

4-channel 5.1-channel 7.1-channel

LineIn/RearSpeakerOut

a a a

Line Out/Front Speaker Out

a a a a

Mic In/Center/Subwoofer

Speaker Out

a a

Front Panel Line Out/Side

Speaker Out

• TheintegratedHD(HighDenition)audioprovidesjackretaskingcapabilitythatallowsthe

user to change the function for each jack through the audio driver.

• Tocongure7.1-channelaudio,youneedtoopentheaudiosoftwareandselectDevice

advancedsettings>PlaybackDevicetochangethedefaultsettingrst.

(Note1) For3rdGenerationAMDRyzen

™

withRadeon

™

Graphics processors only.

(Note2) TheDVI-DportdoesnotsupportD-Subconnectionbyadapter.

(Note3) Only for the A520M DS3H AC.

(Note4) ToenabletheQ-FlashPlusfunctionpleasevisitthe"UniqueFeatures"webpageofGIGABYTE'swebsite.

PleasevisitGIGABYTE'swebsitefordetailsonconguringtheaudiosoftware.

• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefrom

your device and then remove it from the motherboard.

• When removing the cable, pull it straight out from the connector. Do not rock it side to side to

prevent an electrical short inside the cable connector.

- 12 -
