D – KIMWC00412-09EN -18/88
TECHNICAL SPECIFICATIONS
EWLD – EJYNN
(+ OPLR)
600 650 750 800
Capacity Cooling kW
596 657 730 788
Type stepless
Capacity control
Minimum capacity %
12.5
12.5 12.5 12.5
Unit power input Cooling kW
165
181 198 214
EER
3.61 3.63 3.69
3.67
Colour RAL7032
Casing
Material Galvanized and painyedsteel sheet
Height mm
2325 2325 2325 2325
Width mm
1464 1464 1464 1464
Dimensions Unit
Depth mm
4391 4391 4391 4391
Unit kg
3331
3339 3347 3356
Weight
Operating Weight kg
3602
3602 3603 3604
Type Shell and tube
Water volume l
271 263 256 248
Nominal water
flow rate
Cooling l/s 28.49 31.40 34.88 37.64
Nominal Water
pressure drop
Cooling kPa 49 39 52 47
Water heat
exchanger
Evaporator
Insulation material Closed cell foam elastomer
Type Screw compressor
Oil charge l
-
- - -
Compressor
Quantity
2 2 2
Sound Power Cooling dBA
96.9 97.3 97.8 98.9
Sound level
Sound Pressure Cooling dBA 77.8 78.2 78.7 79.8
Refrigerant type R134a
Refrigerant charge kg 5 5 5 5
Refrigerant circuit
N. of circuits
2 2 2 2
Piping connections Evaporator water inlet/outlet mm
168.3
168.3 168.3 168.3
Liquid connections Inlet mm 42 42 42 42
Gas discharge
conn.
Outlet mm 88.9 88.9 88.9 88.9
Water volume LR Version l 170
Safety devices High pressure (pressure switch)
Safety devices Low pressure (pressure switch)
Safety devices Emergency stop
Safety devices High discharge temperature on the compressor
Safety devices Phase monitor
Safety devices Low pressure ratio
Safety devices High oil pressure drop
Safety devices Low oil pressure
Notes
Cooling capacity and power input are based on: 12/7 °C entering/leaving evaporator water
temperature; 45 °C saturated discharge temperature at the compressor
The condenserless units have 3l of oil pre-charge. Total quantity of oil have to be established by the
plant designer
