Surround Display Feature

This motherboard supports surround display upgrade. With the internal VGA output

support (DVI-D, D-Sub and HDMI) and external add-on PCI Express VGA cards,

you can easily enjoy the bene ts of surround display feature.

Please refer to the following steps to set up a surround display environment:

1. Install the PCI Express VGA card on PCIE1 slot. Please refer to page 21 for

proper expansion card installation procedures for details.

2. Connect DVI-D monitor cable to VGA/DVI-D port on the I/O panel, connect D-Sub

monitor cable to VGA/D-Sub port on the I/O panel, or connect HDMI monitor

cable to HDMI port on the I/O panel. Then connect other monitor cables to the

corresponding connectors of the add-on PCI Express VGA card on PCIE1 slot.

3. Boot your system. Press <F2> or <Del> to enter BIOS setup. Enter “Onboard

VGA Share Memory” option to adjust the memory capability to [32MB], [64MB],

[128MB], [256MB] or [512MB] to enable the function of VGA/D-sub. Please make

sure that the value you select is less than the total capability of the system

memory. If you do not adjust the BIOS setup, the default value of “Onboard VGA

Share Memory”, [Auto], will disable VGA/D-Sub function when the add-on VGA

card is inserted to this motherboard.

4. Install the onboard VGA driver and the add-on PCI Express VGA card driver to

your system. If you have installed the drivers already, there is no need to install

them again.

5. Set up a multi-monitor display.

For Windows

XP / XP 64-bit OS:

Right click the desktop, choose “Properties”, and select the “Settings” tab

so that you can adjust the parameters of the multi-monitor according to

the steps below.

A. Click the “Identify” button to display a large number on each monitor.

B. Right-click the display icon in the Display Properties dialog that you

wish to be your primary monitor, and then select “Primary”. When

you use multiple monitors with your card, one monitor will always be

Primary, and all additional monitors will be designated as Secondary.

C. Select the display icon identi ed by the number 2.

D. Click “Extend my Windows desktop onto this monitor”.

E. Right-click the display icon and select “Attached”, if necessary.

F. Set the “Screen Resolution” and “Color Quality” as appropriate for the

second monitor. Click “Apply” or “OK” to apply these new values.

G. Repeat steps C through E for the diaplay icon identi ed by the number

one, two, three and four
