Four Activate Window (tFAW)

Use this item to change Four Activate Window (tFAW) Auto/Manual set-

ting. The default is [Auto].

Memory Power Down Mode

Use this item to adjust DDR power down mode. Configuration options:

[Auto], [Slow] and [Fast]. The default value is [Auto].

Voltage Control

DRAM Voltage

Use this to select DRAM Voltage. Conﬁ guration options: [Auto], [1.250V]

to [1.800V]. The default value is [Auto].

PCH Voltage

Use this to select PCH Voltage. Conﬁ guration options: [Auto], [1.05V] to

[1.15V]. The default value is [Auto].

VTT Voltage

Use this to select VTT Voltage. Conﬁ guration options: [Auto], [1.05V] to

[1.15V]. The default value is [Auto].

VCCSA Voltage

Use this to select VCCSA Voltage. Conﬁ guration options: [Auto], [0.925V]

to [1.107V]. The default value is [Auto].

User Default

In this option, you are allowed to load and save three user defaults

according to your own requirements.
