PCI Latency Timer (PCI Clocks): The default is 32. It is recommended to
keep the default value unless the installed PCI expansion cards’
specifications require other settings.
Primary Graphics Adapter: Select PCI or AGP as the primary graphics adapter.
AGP Data Rate: The default setting is [Auto]. You may select between [8X] or
[4X] for an AGP 3.0 card, or select among [4X], [2X], [1X] for an AGP 2.0
card.
AGP Fast Write: This allows you to enable or disable the feature of AGP fast
write protocal support.
Peripheral Configuration:
OnBoard FDC: Use this to enable or disable floppy drive controller.
OnBoard Serial Port: Use this to set addresses for the onboard serial ports or
disable serial ports. Configuration options: [Auto], [Disabled], [3F8 / IRQ4 /
COM1], [2F8 / IRQ3 / COM2], [3E8 / IRQ4 / COM3], [2E8 / IRQ3 / COM4].
OnBoard Infrared Port: This allows you to enable or disable the onboard
infrared port feature. Select [Enabled] will enable this feature if the infrared
module is installed.
OnBoard Parallel Port: Select Parallel Port address or disable Parallel Port.
Configuration options: [Auto], [Disabled], [378], [278].
Parallel Port Mode: Set the operation mode of the parallel port.
OnBoard Midi Port: Select address for Midi Port or disable Midi Port.
Configuration options: [Disabled], [330], [300], [290], [292].
Midi IRQ Select: Use this to select Midi IRQ. Configuration options: [3], [4],
[5], [7], [10], [11].
OnBoard Game Port: Select address for Game Port or disable Game Port.
Configuration options: [Disabled], [200], [208].
AMIBIOS SETUP UTILITY - VERSION 3.31a
Advanced
OnBoard FDC
OnBoard Serial Port
OnBoard Infrared Port
OnBoard Parallel Port
Parallel Port Mode
EPP Version
Parallel Port IRQ
Parallel Port DMA Channel
OnBoard Midi Port
Midi IRQ Select
OnBoard Game Port
OnBoard IDE
OnBoard LAN
OnBoard AC' 97 Audio
[ Setup Help ]
F1:Help
Esc:Previous Menu
F9:Setup Defaults
F10:Save & Exit
+/-:Change Values
Enter:Select
Sub-Menu
:Select Item
Peripheral Configuration
Auto
Enabled
Auto
Normal
N/A
Auto
N/A
Disabled
5
Disabled
Disabled
Disabled
Disabled
Auto
<Enter> to enable or
disable the floppy
drive controller.
