10
1
:
USB3.2 Gen1 Header (USB3_3_4)
2 : Battery Connector
3 :
M.2 Key-B Socket (M2_KEYB1)
4 : MCU Connector
5 : LPC Header (For IMB-1222 / IMB-1222-WV / IMB-X1222-WV Only)
6 :
SATA3 Connectors (SATA3_1, SATA3_2)
7 :
Digital Input / Output
Default Value Setting (JGPIO_SET1)
8 :
Digital Input / Output Power Select
(JGPIO_PWR1)
9 : Digital Input/Output Pin Header (JGPIO1)
10 : COM Port Headers (COM1, 2, 3, 4)
11 : COM Port PWR Setting Jumpers
PWR_COM1 (For COM Port1)
PWR_COM2 (For COM Port2)
PWR_COM3 (For COM Port3)
PWR_COM4 (For COM Port4)
12 : Backlight Power Select (LCD_BLT_VCC) (BKT_PWR1)
13 : Inverter Power Control Wafer (BLT_PWR1)
14* :
LVDS Panel Connector
* eDP Connector (on the Backside of PCB)
15 : Backlight Control Level (CON_LBKLT_CTL) (BLT_PWM1)
16 : Panel Power Select (LCD_VCC) (PNL_PWR1)
17 : Backlight Volume Control (BLT_VOL1)
18 : SATA Power Output Connector
19
:
USB2.0 Headers
(USB2_11_12, USB2_8_9)
* USB2_11_12 is for IMB-1222 / IMB-1222-WV / IMB-X1222-WV Only.
20 :
CPU FAN Connector (+12V)
21
:
System Panel Header
22 : SMBUS_TEST1
23 : Chassis Intrusion Header (CI1)
24 : Clear CMOS Header (CLRMOS1)
25 : SIO_AT1
26 :
Chassis FAN Connector (+12V)
27 : EDP_LVDS_SWITCH1
28 : AC PWR LOSS Header (AC_PWR_LOSS1)
29 : M.2 Key-M Socket (M2_KEYM1)
30 : M.2 Key-E Socket (M2_KEYE1)
31 : Power Adapter (For IMB-1222-WV / IMB-X1222-WV Only)
32 : 4-pin ATX PWR Connector
33 : 2-pin UPS Module Power Input Connector
34 :
SPDIF Header
35 :
Front Panel Audio Header
36 :
3W Audio AMP Output Wafer
37 : VGA Header (For IMB-1223 / IMB-1223-WV Only)
38 : ThunderBolt Header
Back Side :
SIM Card Socket (SIM1) (For IMB-1222-WV / IMB-X1222-WV / IMB-1223-WV Only)
eDP Connector (EDP1, refer to No. 14)
