1 :COM Port PWR Setting Jumpers
PWR_COM1 (For COM Port1)
PWR_COM2 (For COM Port2)
2 : 4-pin ATX Power Input/Output Connector
3 : 24-pin ATX Power Input Connector
4 : SATA Power Output Connector
5 : SATA3 Connectors (SATA3_1~4)
6 :
USB2.0 Headers (
USB2_8_9, USB2_11_12
)
* USB2_11_12 is for IMB-1220 / IMB-X1220 only.
7 :
USB3.2 Gen1 Header (
USB3_3_4)
8 : M.2 Key-B Socket (M2B1)
9 :
4-Pin CPU FAN Connector (+12V) (CPU_FAN1)
10 : Clear CMOS Header (CLRMOS1)
11 : Chassis Intrusion Header (CI1)
12 :
Backlight Power Select (LCD_BLT_VCC) (BKT_PWR1)
13 : Inverter Power Control Wafer (BLT_PWR1)
14 : Backlight Volume Control (BLT_VOL1)
15* :
LVDS Panel Connector (IMB-1220-L)
* eDP Connector (on the Backside of PCB) (IMB-1220-D)
16 : Panel Power Select (LCD_VCC) (PNL_PWR1)
17 : LVDSBL1, LVDSBL2
18 : Chassis Intrusion Header (CI2)
19 : TPM Header (For IMB-1220 / IMB-X1220 Only)
20 : Backlight Control Level (CON_LBKLT_CTL) (BLT_PWM1)
21 : COM Port Headers (COM3, 4, 5) (RS232)
* COM5 is for IMB-1220 / IMB-X1220 only.
22 :
4-Pin Chassis FAN Connector (+12V)
23 :
System Panel Header
24 : COM Port PWR Setting Jumpers
PWR_COM3 (For COM Port3)
PWR_COM4 (For COM Port4)
PWR_COM5 (For COM Port5) (For IMB-1220 / IMB-X1220 only)
25 : Buzzer
26 : SIO_AT1
27 : Digital Input/Output Pin Header (JGPIO1)
28 :
Digital Input / Output
Default Value Setting (JGPIO_SET1)
29 : M.2 Key-M Socket (M2M_1)
30 : M.2 Key-E Socket (M2E_1)
31 : PWR LOSS Header (PWR_LOSS1)
32 : 3W Audio AMP Output Wafer
33 : SPDIF Header
34 : PWR_BAT1
35 : Clear CMOS Header (CLRMOS2)
36 : Battery Connector
37 :
Front Panel Audio Header
Back Side :
SIM Card Socket (SIM1)
eDP Connector (EDP1) (IMB-1220-D)
MCU Connector (MCU_CON1)
