7
LVDS
Dual channel 24 bit up to 1920x1200@60Hz
(IMB-1220-L)
eDP
eDP 1.4, Max resolution up to
4096x2304@60Hz (IMB-1220-D)
DVI N/A
MultiDisplay
IMB-1220 / IMB-X1220: Triple Display
IMB-1221: Dual Display
Ethernet
Controller/
Speed
IMB-1220 / IMB-X1220:
LAN1: Intel
®
I225LM with 10/100/1000/2500
Mbps
LAN2: Intel
®
I219LM, with 10/100/1000
Mbps, support AMT/vPro
IMB-1221:
LAN1: Intel
®
I225LM with 10/100/1000/2500
Mbps
LAN2: Intel
®
I219V with 10/100/1000 Mbps
Connector 2 x RJ-45
Audio
Interface
Realtek ALC887 HD, High Denition Audio.
Line-out, Mic-in.
Rear I/O
HDMI 1 x HDMI 2.0a
DisplayPort
1 x DP 1.2 (IMB-1220-L)
2 x DP 1.2 (IMB-1220-D)
VGA 1 (IMB-1220-L)
DVI N/A
Ethernet 1 x 1 Gigabit LAN + 1 x 2.5 Gigabit LAN
USB
IMB-1220 / IMB-X1220: 4 x USB 3.2 (Gen1)
IMB-1221: 2 x USB 3.2 (Gen1) + 2 x USB
2.0
Audio 2 (Mic-in, Line-out)
COM 2 x COM (RS232/422/485)
PS2 N/A
Internal
Connector
USB
2 x USB 3.2 Gen1 (1 x USB 3.2 Gen1
header)
IMB-1220 / IMB-X1220:
4 x USB 2.0 (2 x 2.54 pitch header)
IMB-1221:
2 x USB 2.0 (1 x 2.54 pitch header)
COM
IMB-1220 / IMB-X1220: 3 x COM (RS232)
IMB-1221: 2 x COM (RS232)
Parallel N/A
GPIO 4 x GPI, 4 x GPO
