7
Rear I/O
VGA 1 (shared with HDMI)
DVI 0
HDMI 1
DisplayPort 1
Ethernet 2
USB 4 x USB 3.0
Audio 2 (Mic-In, Line-Out)
eSATA 0
PS/2 0
Internal
Connector
USB 6 (2 x USB Header 2.54mm pitch)
LVDS/
Inverter
24 bit dual channel LVDS
VGA 1
Serial 6 (2 x RS-232/422/485, 4 x RS-232)
SATA 2 x SATA3 (6.0Gb/s)
mPCIe 1
Parallel 1 (Co-lay with DIO)
mSATA 1
PS/2 1
GPIO 16-bit 8 x GPI + 8 x GPO (Co-lay with LPT)
SATA PWR
Output Con
2
Speaker
Header
1
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR DC 9-19 input
Power On
AT/ATX Supported
AT : Directly PWR on as power input ready
ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
