7
Internal
Connector
USB 5 x USB2.0 (2 x headers, 1 x Type A)
LVDS 1 (shared with eDP, auto detect)
eDP 1
VGA 1 (shared with VGA Con.)
Serial
2 x COM (RS-232/422/485), 4 x
COM(RS-232)
SATA 1 x SATA3 (6.0Gb/s)
Parallel 1 (shared with GPIO)
GPIO 8 x GPI, 8 x GPO
SATA PWR
Output Con
1
Speaker
Header
1
TPM Header 1
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR
+12V or +19V~+28V DC-In (DC Jack / 4-pin
DC-in PWR Connector)
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
