7
Rear I/O
VGA 1
DVI 0
HDMI 1
DisplayPort 0
Ethernet 2
USB 4 x USB 3.0
Audio 2 (Mic-in, Line-out)
Serial 3 x COM (Supports RS-232/422/485)
PS/2 2
Internal
Connector
USB 4 x USB 2.0 (2 x 2.54 pitch header)
LVDS/
Inverter
1/1
eDP 1
VGA 1
Serial 3 x COM (Supports RS-232 only)
SATA 1
mPCIe 1
Parallel 1 (shared with GPIO)
mSATA 0
IrDA 0
GPIO 8-bit
8 x GPI + 8 x GPO (shared with LPT
header)
SATA PWR
Output Con
1
Speaker
Header
1
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR
- +12V or +19V~+24V DC-In (4-pin ATX
PWR Con)
- ATX PWR 20-pin
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment
Temperature 0ºC – 60ºC
