14 SATA3 Connector (SATA3_4, White)
15 SATA3 Connector (SATA3_2, White)
16 SATA3 Connector (SATA3_3, White)
17 SATA3 Connector (SATA3_1, White)
18 COM Port Header (COM3)
19 COM Port Header (COM4)
20 System Panel Header (PANEL1)
21 PWR-On Mode Jumper (PWR_JP1)
22 COM Port Header (COM6)
23 COM Port Header (COM5)
24 COM Power Setting Jumper (SET_CM3)
25 Digital I/O Header (DIO1)
26 COM Power Setting Jumper (SET_CM4)
27 Clear CMOS Jumper (CLRCMOS1)
28 Buzzer (BUZZ1)
29 USB 2.0 Header (USB6_7)
30 USB 2.0 Header (USB8_9)
31 USB 2.0 Header (USB10_11)
32 PCI Express Slot (PCIE1)
33 Vertical Type A USB (USB12)
34 Audio AMP Output Speaker Header (SPEAKER_OUT1)
35 Front Panel Audio Header (HD_AUDIO1)
36 TPM header (TPM1)
37 SPI Flash Memory (32Mb)
38 Chassis Fan Connector (CHA_FAN1)
39 COM Power Setting Jumper (SET_CM2)
40 COM Power Setting Jumper (SET_CM1)
41 mini PCI Express Slot (MINI_PCIE1)
* LVDS for IMB-A160 only.
