Power on Mode - AT/ATX Power on mode supported (setting by jumper)
AT: Directly PWR on as Power input ready
ATX: Press Button to PWR on after Power input ready
RTC - eKabini embedded
Internal I/O
Display - LVDS (2-ch/24bits) + Inverter connector
(IMB-A180) - 1 x rear HDMI
Display - 2 x rear HDMI
(IMB-A180-H)
Storage - 1 x SATA3 port
- 1 x mSATA
USB - 2 x USB2.0 ports (by Header)
- 1 x Vertical Type A USB Connector
Audio - Front Audio Header
- Buzzer
Serial Port - 4 x RS232
- 4 x (1x3) Header to offer PWR select for 2 rear and 2
internal
Parallel Port - 1 x LPT Header (2x13, K26, 2.0mm)
Digital I/O - 8-bits
Battery - Vertical socket
FAN - 1 x 3-pin FAN (with speed control)
- 1 x 4-pin FAN Connector
Power In - 20-pin ATX PWR connector
Front Panel - One 2x5 K10 pin Header to offer: PWR Button / Reset
Button / PWR/Suspend LED / HDD LED
TPM - TPM Header
Others - 1 x 7-pin pitch 2.0 wafer connector for LVDS brightness
control and audio volume control (IMB-A180)
- AMD Debug Header
Rear I/O
Keyboard/Mouse - 1 x PS/2 combo
(PS/2)
Serial Port - 2 x RS-232/422/485, pin9 with +5V/+12V support
LAN - 2 x RJ45
USB2.0 - 4 x USB2.0
USB3.0 - 2 x USB3.0
