7
USB 4 x USB 3.0
Audio 2 (Mic-in, Line-out)
Serial
3 x RS-232 (COM1/COM2/COM3 support
RS-422/485)
PS/2 PS2 x2, KB & MS stack
Internal
Connector
USB 4 (2 x 2.54 pitch header USB 2.0 compliant)
LVDS/
Inverter
1/1
VGA 0
Serial 3 x 2.0 pitch header RS-232
SATA 2 x SATA3 (6.0Gb/s)
mPCIe 1
Parallel 1 (Co-lay with 8in/8out DIO)
mSATA 1(Share with SATA3)
IrDA 0
GPIO 8-bit 8 x GPI + 8 x GPO
SATA PWR
Output Con
1
Speaker
Header
1
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR
12V or 19~24V DC in (4-pin ATX PWR Con)
/ ATX
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
