7
DisplayPort 0
Ethernet 1
USB 4
Audio 2 (Mic-In, Line-Out)
Serial 0
PS/2 0
Internal
Connector
USB 4 (USB 2.0 compliant)
LVDS/
Inverter
1/1
VGA 1 (shared with rear I/O VGA COM)
Serial 2 ( RS232) / 4 from TPM header
SATA 2 x SATA2 ( 3.0Gb/s)
mPCIe 1 + 1 shared
Parallel 1
mSATA 1 shared
IrDA 0
GPIO 8-bit 4 in / 4 out
SATA PWR
Output Con
1
Speaker
Header
1
Watchdog
Timer
Output From Super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR 9~19V DC-In (DC-Jack or 2-pin PWR Con)
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
