11
1 Rear Fan Connector (REAR_FAN1)
2 ATX Power Connector (ATXPWR1)
3 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2, White)
4 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1, Blue)
5 Front Fan Connector (FRNT_FAN1)
6 CPU Fan Connector (CPU_FAN1)
7 CPU Fan Connector (CPU_FAN2)
8 1155-Pin CPU Socket
9 Front Fan Connector (FRNT_FAN2)
10 Front Lan LED Connector (FRONT_LED_LAN34)
11 Auxiliary panel header (AUX_PANEL1)
12 SATA3 Connector (SATA_0_1, White)
13 SATA2 Connector (SATA_2_3, Blue)
14 SATA2 Connector (SATA_4_5, Blue)
15
SATA3 Connector (SATA3_M0_M1, White)
16 Serial General Purpose Input/Output Header (SGPIO_1)
17 SPI Flash Memory (64Mb)
18 Front Fan Connector (FRNT_FAN3)
19 System Panel Header (PANEL1)
20 Speaker Header (SPEAKER1)
21 USB 2.0 Header (USB4_5, Blue)
22 Buzzer (BUZZER1)
23 USB 2.0 Header (USB2_3, Blue)
24 Intelligent Platform Management Bus header (IPMB_1)
25 ME Recovery Jumper (ME_RECOVERY1)
26 Clear CMOS Pad (CLRCMOS2)
27 COM Port Header (COM2)
28 Intel C204 Chipset
29 USB 2.0 Ports (USB6)
30 PSU SMBus (PSU_SMB1)
31 TPM header (TPM1)
32 Non Maskable Interrupt Button (NMI_BTN1)
33 Thermal Sensor header (TR1)
34 PCI Slot (PCI1, White)
35
PCI Express 2.0 x4 Slot (PCIE2, White)
36
PCI Express 2.0 x1 Slot (PCIE3, White)
37
PCI Express 3.0 x16 Slot (PCIE4, Blue)
38
PCI Express 2.0 x1 Slot (PCIE5, White)
39
PCI Express 3.0 x16 Slot (PCIE6, Blue)
40 ATX 12V Power Connector (ATX12V1)
