8
* For detailed product information, please visit our website: http://www.asrock.com
Serial Port 1 (COM1)
Internal
Connectors
COM Port
Header
1 (COM2)
Auxiliary
Panel
Header
1 (Includes chassis intrusion, location button &
LED, front LAN LED)
TPM Header 1
IPMB
Header
E3C204-4L / E3C204
1
E3C204-V4L / E3C204-V+
N/A
Buzzer 1
Fan Header 6 (5 x 4-pin, 1 x 3-pin)
ATX Power
1 (24-pin) + 1 (8-pin)
USB Header
2 (Each supports 2 USB 2.0)
Type A USB
2.0 Port
1
System
BIOS
BIOS Type 64Mb AMI UEFI Legal BIOS with GUI support
BIOS
Features
Plug and Play (PnP)
ACPI 1.1 Compliance Wake Up Events
Supports jumperfree
SMBIOS 2.3.1 Support
DRAM Voltage Multi-adjustment
Hardware
Monitor
Temperature
CPU Temperature Sensing
System Temperature Sensing
Fan
CPU/Rear/Front Fan Tachometer
CPU Quiet Fan (Allow Chassis Fan Speed
Auto-Adjust by CPU Temperature)
CPU/Rear/Front Fan Multi-Speed Control
Voltage
Voltage Monitoring: +12V, +5V, +3.3V, CPU
Vcore, DRAM, VTT, 1.05V_PCH, +BAT, 3VSB,
5VSB
Support OS OS
Microsoft
®
Windows
®
Server 2003 / 2003 R2 /
2008 / 2008 R2 / Linux compliant
Features
Unique
Features
ASRock Instant Flash
