104
FEATURES AND OPTIONS
RGBW WWCW NWDW
RDMDMX RFU
IK09 IK10IP67
1.8 KG 2.8 KG 4.1 KG 5.3 KG
BEAM ANGLE REFERENCE
PHOTOMETRIC DETAILS AVAILABLE ON OUR WEBSITE
ACCESSORIES
PARADE
L-1
L-2
L-3
L-4
914 mm [36”]
70 mm
1219 mm [48”]
610 mm [24”]
318 mm
70 mm
76 mm
[12.5”]
[2.7”]
[3”]
+90°-90°
RAL9003
GRIVEN GREY
RAL7016 RAL9005
CLASS
SELFADDR
DIGITAL CONTROL SYSTEM SPECIFICATIONS AND CONFIGURATIONS AVAILABLE ON OUR WEBSITE
TECHNICAL SPECIFICATIONS
The linear bars of the PARADE L series are high luminance IP67 linear modules, whose extruded aluminium
body hosts either 12, 24, 36 or 48 high brightness RGBW or Dynamic White LEDs or 6, 12, 18 or 24 Cold White,
Natural White, Warm White or, on request, monochrome power LEDs. Dimensions: 318/610/914/1219 mm x 76
mm x 70 mm. Available in DMX, Automatic and Master-Slave mode, they also feature RFU (Remote Firmware
Update) and RDM (Remote Device Management) functions. Self-addressing, DALI or Independent Pixel control
available on request. One Infrared Remote Control AL1321 must always be purchased in order to access DMX
addressing, stand-alone operations and DMX channels congurations for DMX/RDM and Independent Pixels
versions, unless an RDM compatible control is used. Power supply: standard 100÷277V / 50-60Hz. Power
consumption: L-1 0.097A @ 230V / 21W max. L-2 0.19A @ 230V / 42W max. L-3 0.28A @ 230V / 63W max. L-4
0.37A @ 230V / 84W max. An Electrical Class I appliance, it also features self-resetting fuse protection as well
as integrated electronic thermal protection management. The Polar Edition, fitted with an integrated de-icing
system with electrically heated glass, is available on request. Operating temperature: -40°C to 50°C (-40°F to
122°F).
CODES
AL5060 PARADE L-1
AL5061 PARADE L-1 PE
AL5065 PARADE L-2
AL5066 PARADE L-2 PE
AL5070 PARADE L-3
AL5071 PARADE L-3 PE
AL5075 PARADE L-4
AL5076 PARADE L-4 PE
OPTICS
SP Spot
NA Narrow
ME Medium
WI Wide
EW Extra wide
EL Elliptical
WL Elliptical Wide
WW Wall Wash
CABLE TYPE
C Monocable with connectors
M Monocable without connectors
LED TYPE
RN RGB+W 4000K
DW From 2700K to 6500K
CW Cold White 6500K
NW Natural White 4000K
WW Warm White 3000K
CONTROL SYSTEM
R DMX-RDM
S Self-addressing
D DALI
I Independent Pixels
FINISH
W White RAL 9003
G GRIVEN Grey
A Anthracite RAL 7016
B Black RAL 9005
L1
L1 /L3 L2/L4
L2 L3 L4
AL5169
DMX TERMINATOR
AL5058 C
START LINE BOX
(with connectors)
AL5058 M
START LINE BOX
(without connectors)
AL5167 C
REPOWER BOX
(with connectors)
AL5167 M
REPOWER BOX
(without connectors)
AL5059 C
DMX JUNCTION
BOX
(with connectors)
AL5059 M
DMX JUNCTION
BOX
(without connectors)
AL5096 VISOR L-1
AL5097 VISOR L-2
AL5098 VISOR L-3
AL5099 VISOR L-4
AL5174 BEEHIVE L-1
AL5175 BEEHIVE L-2
AL5176 BEEHIVE L-3
AL5177 BEEHIVE L-4
AL1321 INFRARED
REMOTE CONTROL
AL5103 SNOOT L-1
AL5104 SNOOT L-2
AL5105 SNOOT L-3
AL5106 SNOOT L-4
AL5055 80mm BRACKETS
AL5056 160mm BRACKETS
AL5057 260mm BRACKETS
MAX OUTPUT
7560 lm
(SP CW conguration)
WHITE LIGHT
SPOT 12°
NARROW 15°
MEDIUM 25°
WIDE 48°
EXTRA WIDE 59°
ELLIPTICAL 14°x39°
ELLIPTICAL WIDE 23°x38°
WALL WASH 19°(5°
incline
)x38°
RGBW
SPOT 7°
NARROW 11°
MEDIUM 21°
WIDE 43°
EXTRA WIDE 69°
ELLIPTICAL 9°x41°
ELLIPTICAL WIDE 20°x38°
WALL WASH 13°(5°
incline
)x37°
AL8264 1 m CONNECTION CABLE
AL8265 2 m CONNECTION CABLE
AL8266 3 m CONNECTION CABLE
AL8267 5 m CONNECTION CABLE
AL8268 10 m CONNECTION CABLE
NOTES
One Infrared Remote Control AL1321 must always be purchased for DMX/RDM and independent pixels
versions, unless an RDM compatible control is used. More PARADE L units can be controlled with one AL1321.
PARADE L must always be purchased with xing brackets (see accessories).
IND. PIX.
DALI
ANTISALINE
WIRELESS DATA
POLAR
