148
MICRO-DUNE
MC/MK2 W
FEATURES AND OPTIONS
IK08 IK08IP67 IP67
1.9 KG 2.1 KG
BEAM ANGLE REFERENCE
PHOTOMETRIC DETAILS AVAILABLE ON OUR WEBSITE
ACCESSORIES
RGBW WWCW NW
RDMDMX RFU
RGBW-DW
NARROW 14°
MEDIUM 28°
WIDE 40°
DIGITAL CONTROL SYSTEM SPECIFICATIONS AND CONFIGURATIONS AVAILABLE ON OUR WEBSITE
TECHNICAL SPECIFICATIONS
MICRO-DUNE MC is an IP67 ultra compact recessed uplighter, whose die cast aluminium case tted with
stainless steel ange hosts 3 high brightness RGBW or tunable white multichip power LEDs. Dimensions: Ø
150/136 mm x 105/100 mm depth. Available in remote DMX mode, it also features RFU (Remote firmware
update) and RDM (Remote device management) functions. Power supply: 48V DC. Power consumption:
13.5W. An Electrical Class III appliance, it works with an IP67 separate electronic driver featuring self-resetting
fuse protection, powering up to 12 units.. Integrated electronic thermal control management. A 3000
Kg deadweight load capacity makes it suitable for ground mounting applications even in vehicular areas.
Operating temperature: -40°C to 40°C (-40°F to 104°F).
MICRO-DUNE MK2 W is an IP67 ultra compact recessed uplighter whose die cast aluminium case tted
with stainless steel ange hosts 3 high brightness Cold White, Natural White or Warm White power LEDs.
Dimensions: Ø 150/136 mm x 105/100 mm depth. Power supply: 100÷277V / 50-60Hz. Power consumption:
6.9W per unit. An Electrical Class I appliance, it features an in-built power supply. A 3000 Kg deadweight load
capacity makes it suitable for ground mounting applications even in vehicular areas. Operating temperature:
-20°C to 40°C (-4°F to 104°F).
CODES
AL5243 MICRO-DUNE MC
AL5244 MICRO-DUNE MK2 W
LED TYPE
RN RGB+W 4000K
DW From 2700K to 6500K
LED TYPE
CW Cold White 6500K
NW Natural White 4000K
WW Warm White 3000K
OPTICS
NA Narrow
ME Medium
WI Wide
OPTICS
SP Spot
NA Narrow
ME Medium
WI Wide
EW Extra wide
EL Elliptical
WL Elliptical Wide
MAX LOAD
3000
kg
MAX LOAD
3000
kg
150 mm
105 mm
136 mm
100 mm
[5.9”]
[4.1”]
[5.3”]
[4.1”]
150 mm
105 mm
136 mm
100 mm
[5.9”]
[4.1”]
[5.3”]
[4.1”]
AL8213 IP67 SEPARATE ELECTRONIC
DRIVER (only for RGBW versions)
AL8261 ANTIGLARE
(only for monochrome versions)
WHITE LIGHT
SPOT
NARROW
MEDIUM
WIDE
EXTRA WIDE
ELLIPTICAL
ELLIPTICAL WIDE
MC
MAX OUTPUT
725 lm
(SP CW conguration)
NOTES
Unless an RDM control is used, MICRO-DUNE MC must always be purchased with one AL2660 WeeZerd 1 to set
its DMX address. The RGBW and DW versions require an external power supply unit. The white version is fitted
with integrated power supply unit and does not feature DMX options.
CLASS
III
CLASS
DW
AL2660
WEEZERD 1
12°
15°
25°
47°
61°
14°x39°
23°x37°
