Teka DV 80 GLASS Инструкция по эксплуатации онлайн [5/8] 64581
![Teka DV 80 GLASS Инструкция по эксплуатации онлайн [5/8] 64581](/views2/1070093/page5/bg5.png)
1 150/ 120 mm reduction.
2 Support for tubecover.
2 Wall support.
6 Wall plugs (Ø8 x 40).
6 Long bolts (Ø5 x 45).
4 Wall plugs (Ø6 x 30).
4 Long bolts (Ø4 x 30).
2 Ø6,4 x Ø18, washers.
2 Ø6,4 x Ø12, washers.
2 Screws (Ø3,9 x 20).
4 Screws (Ø4 x 12).
2 Clips.
FFiigg.. 11 ((PPaaggee 3311))
OOnn iinnssttaalllliinngg tthhee kkiittcchheenn hhoooodd mmaakkee ssuurree
tthhaatt tthhee SSaaffeettyy IInnssttrruuccttiioonnss sseett oouutt oonn
ppaaggee
1100 aarree ccoommpplliieedd wwiitthh..
To obtain optimum performance, the external
conduct must not be more than FOUR
METRES long, have no more than two 90°
angles and its diameter must be at least Ø120.
1) Trace and drill the points for fitting the wall
plugs onto the wall (P) (Ø8 x 40) and (J) (Ø6 x
30).
2) Attach the Supports (O) to the wall using the
long bolts (Q) (Ø5 x 45) and the support (H)
with the long bolts (I) (Ø4 x 30), as in figure 1.
3) Hang the kitchen hood onto the mounted
supports (O). Straighten the appliance by
tightening the long bolts (L) (M4 x 12).
4) Open the lateral doors. Remove the metal
filters.
5) Drill into the wall and fit the wall plugs (R)
(Ø8 x 40), through the inside of the kitchen
hood.
6) Tighten the screws (M) (M4 x 12) with the
washers (A3) (Ø6,4 x Ø12) and the long bolts
(S) (Ø5 x 45) with the washers (T) (Ø6,4 x
Ø18).
7) Fit the metal filters. Close the lateral door.
8) Mount the tubecovers, attaching the lower
one to the support (H) as per the detail in figure
1. Lift the upper tubecover up to the desired
height and mark its shape on the wall. Remove
the tubecovers.
9) Fit the clips (F) to the support (C).
10) Centre the support (C) around the shape
marked; trace and drill the fixing points for the
wall plugs (E) (Ø6 x 30). Attach the support (C)
with the long bolts (D) (Ø4 x 30).
11) Fit the part (B) if the inner tube (not
supplied) is Ø120.
12) Attach the inner tube with a clamp (not
supplied) to (B) or on to the motor's air outlet
vent as the case may be.
13) Once the inner tube is fitted, fit the lower
tubecover around the extractor fan outlet and
attach the upper tubecover with the screws (G)
(Ø3,9 x 20).
When exterior gas extraction is not possible,
then the kitchen hood may be set to purify the
air by recycling it through active charcoal
filters.
The active charcoal filters have an active life of
between three to six months, depending on
the individual conditions of use. These filters
cannot be washed nor regenerated. They must
be replaced once their useful life comes to an
end.
FFiigg.. 22 ((PPaaggee 3311))
1) Trace and drill the points for fitting the wall
plugs onto the wall (P) (Ø8 x 40) and (J) (Ø6 x
30).
2) Attach the Supports (O) to the wall using the
long bolts (Q) (Ø5 x 45) and the support (H)
with the long bolts (I) (Ø4 x 30), as in figure 1.
3) Hang the kitchen hood onto the mounted
supports (O). Straighten the appliance by
tightening the long bolts (L) (M4 x 12).
4) Open the lateral doors. Remove the metal
filters.
5) Drill into the wall and fit the wall plugs (R)
(Ø8 x 40), through the inside of the kitchen
hood.
6) Tighten the screws (M) (M4 x 12) with the
washers (A3) (Ø6,4 x Ø12) and the long bolts
(S) (Ø5 x 45) with the washers (T) (Ø6,4 x
Ø18).
7) Put the filters into the lateral draught section
of the motor making the holes in the filters
match up (A11) with the pivots (A12) of the
motor carcass. Turn as indicated in the
diagram.
8) Fit the metal filters. Close the lateral door.
IIff tthhee kkiitt iiss nnoott iinncclluuddeedd iinn tthhee ccooookkeerr hhoooodd::
Fit the diffuser (A5) on to the motor's air outlet
vent with the screws (A4).
SSeenndd tthhee ttuubbeeccoovveerrss ttoo aann aauutthhoorriizzeedd
rreeccyycclliinngg aarreeaa..
AAccttiivvee cchhaarrccooaall ffiilltteerrss ((OOppttiioonnaall))
IInnssttaallllaattiioonn
AAcccceessoorriieess ssuupppplliieedd
13
ENG
