SiENBE37-704 Specifications
Specifications 13
Notes:
H1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference
: 0m.
Model Name (Combination Unit) REYQ18P8Y1B REYQ20P8Y1B
Model Name (Independent Unit) REMQ8P8Y1B+REMQ10P8Y1B REMQ8P8Y1B+REMQ12P8Y1B
H1 Cooling Capacity (19.5°CWB)
kcal / h 43,600 48,300
Btu / h 173,000 192,000
kW 50.7 56.2
H2 Cooling Capacity (19.0°CWB) kW 50.4 55.9
H3 Heating Capacity
kcal / h 48,600 53,800
Btu / h 193,000 213,000
kW 56.5 62.5
Casing Color
Y1 Type Ivory White 5Y7.5/1 Ivory White 5Y7.5/1
Y1E Type Light Camel 2.5Y6.5/1.5 Light Camel 2.5Y6.5/1.5
Dimensions: (H×W×D) mm 1680×930×765+1680×930×765 1680×930×765+1680×930×765
Heat Exchanger Cross fin coil Cross fin coil
Comp.
Type Hermetically sealed scroll type Hermetically sealed scroll type
Piston Displacement m³/h (13.34+10.53)+16.90 (13.34+10.53)+16.90
Number of Revolutions r.p.m (6300, 2900), 7980 (6300, 2900), 7980
Motor Output×Number
of Units
kW (2.2+4.5)×1+4.7×1 (3.5+4.5)×1+4.7×1
Starting Method Soft start Soft start
Fan
Type Propellor fan Propellor fan
Motor Output kW (0.75×1)+(0.75×1) (0.75×1)+(0.75×1)
Air Flow Rate
I/s 3,000+3,083 3,000+3,333
m³/min 180+185 180+200
Drive Direct drive Direct drive
Connecting
Pipes
Liquid Pipe φ15.9 C1220T (Brazing connection) φ15.9 C1220T (Brazing connection)
Suction Gas Pipe φ28.6 C1220T (Brazing connection) φ28.6 C1220T (Brazing connection)
High and Low Pressure Gas Pipe φ22.2 C1220T (Brazing connection) φ28.6 C1220T (Brazing connection)
Pressure Equalizer Tube φ19.1 C1220T (Brazing connection) φ19.1 C1220T (Brazing connection)
Mass (Weight) kg 204+254 204+254
Safety Devices
High pressure switch, fan driver overload protector,
overcurrent relay, inverter overload protector
High pressure switch, fan driver overload protector,
overcurrent relay, inverter overload protector
Defrost Method Deicer Deicer
Capacity Control % 9~100 7~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 8.2+9.0 8.2+9.1
Control Electronic expansion valve Electronic expansion valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation manual, Operation manual, Connection pipes,
Cramps
Installation manual, Operation manual, Connection pipes,
Cramps
Drawing No. 4D057568A 4D057569A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
