SiENBE37-704 Specifications
Specifications 17
Notes:
H1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference
: 0m.
Model Name (Combination Unit) REYQ34P8Y1B REYQ36P8Y1B
Model Name (Independent Unit) REMQ8P8Y1B+REMQ10P8Y1B+REMQ16P8Y1B REMQ8P8Y1B+REMQ12P8Y1B+REMQ16P8Y1B
H1 Cooling Capacity (19.5°CWB)
kcal / h 82,600 87,700
Btu / h 328,000 348,000
kW 96.0 102
H2 Cooling Capacity (19.0°CWB) kW 95.4 101
H3 Heating Capacity
kcal / h 92,000 97,200
Btu / h 365,000 386,000
kW 107 113
Casing Color
Y1 Type Ivory White 5Y7.5/1 Ivory White 5Y7.5/1
Y1E Type Light Camel 2.5Y6.5/1.5 Light Camel 2.5Y6.5/1.5
Dimensions: (H×W×D) mm 1680×930×765+1680×930×765+1680×1240×765 1680×930×765+1680×930×765+1680×1240×765
Heat Exchanger Cross fin coil Cross fin coil
Comp.
Type Hermetically sealed scroll type Hermetically sealed scroll type
Piston Displacement m³/h (13.34+10.53+10.53)+(13.34+10.53)+16.90 (13.34+10.53+10.53)+(13.34+10.53)+16.90
Number of Revolutions r.p.m (6300, 2900, 2900)+(6300, 2900)+7980 (6300, 2900, 2900)+(6300, 2900)+7980
Motor Output×Number
of Units
kW (3.2+4.5+4.5)×1+(2.2+4.5)×1+4.7×1 (3.2+4.5+4.5)×1+(3.5+4.5)×1+4.7×1
Starting Method Soft start Soft start
Fan
Type Propellor fan Propellor fan
Motor Output kW (0.75×1)+(0.75×1)+(0.35×2) (0.75×1)+(0.75×1)+(0.35×2)
Air Flow Rate
I/s 3,000+3,083+3,833 3,000+3,333+3,833
m³/min 180+185+230 180+200+230
Drive Direct drive Direct drive
Connecting
Pipes
Liquid Pipe φ19.1 C1220T (Brazing connection) φ19.1 C1220T (Brazing connection)
Suction Gas Pipe φ34.9 C1220T (Brazing connection) φ41.3 C1220T (Brazing connection)
High and Low Pressure Gas Pipe φ28.6 C1220T (Brazing connection) φ28.6 C1220T (Brazing connection)
Pressure Equalizer Tube φ19.1 C1220T (Brazing connection) φ19.1 C1220T (Brazing connection)
Mass (Weight) kg 204+254+334 204+254+334
Safety Devices
High pressure switch, fan driver overload protector,
overcurrent relay, inverter overload protector
High pressure switch, fan driver overload protector,
overcurrent relay, inverter overload protector
Defrost Method Deicer Deicer
Capacity Control % 5~100 5~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 8.2+9.0+11.7 8.2+9.1+11.7
Control Electronic expansion valve Electronic expansion valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation manual, Operation manual, Connection pipes,
Cramps
Installation manual, Operation manual, Connection pipes,
Cramps
Drawing No. 4D057811A 4D057812A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
