Before you proceed with the installation, it is necessary that you have enough

information about WAP-6200.

1. Please connect right installationà “PoE” port of PoE inject to WAP-6200; “LAN”

port of PoE injector to LAN PC, wrong installation will cause the device damage.

Note

Strongly suggest using SFTP cable, for better protection of the data

wire. 25-meter SFTP cable also available by order, the part no is

WL-SFTP-25. Please contact with local dealer for more information.

2. Using Category 3 or higher UTP or STP cable, connect the “LAN” port of PoE

Injector to a 10Mbps or 10/100Mbps Ethernet hub or switch, and connect the PC

on the same LAN for management.

3. Locate an optimum location and use the provided Mounting kit to tie the WAP-

6200 to a pole.

Note

1. To avoid thunder strike, consider to install ELA-100, thunder

arrester toward the CPE AP and the PoE injector.

2. For secured reason, while install the CPE AP, please be aware for

the electric wires around, and tighten the pole.

Without tighten the CPE AP, the pole and the installed site is

with electric wire around, there could be danger of being hurt by

falling or lethal injury.

4. Connect the 12V 1.25A DC power adapter to the PoE Injector socket, and plug it

into an AC outlet to power on the WAP-6200.

Note

1. ONLY use the power adapter supplied with the WAP-6200. Otherwise, the

product may be damaged.

2. Strongly suggest using SFTP cable whether the cable exposed outdoor for

waterproof and avoiding thunder stroke.

5. For LAN and WAN port application, please refer to Chapter 5 or Chapter 6 of

manual for gateway, bridge, and WISP application for the rst installation, LAN

port is suggested.
