Before you proceed with the installation, it is necessary that you have enough

information about WNAP-7200.

1. Please connect right installation “PoE” port of PoE inject to WNAP-7200; “LAN”

port of PoE injector to LAN PC, wrong installation will cause the device damage.

Note

Strongly suggest using SFTP cable, for better protection of the data

wire. 25-meter SFTP cable also available by order, the part no is

CB-STP-25. Please contact with local dealer for more information.

2. Using Category 3 or higher UTP or STP cable, connect the “LAN” port of PoE

Injector to a 10Mbps or 10/100Mbps Ethernet hub or switch, and connect the PC

on the same LAN for management.

3. Locate an optimum location and use the provided Mounting kit to tie the WNAP-

7200 to a pole.

Note

1. To avoid thunder strike, consider installing ELA-100, thunder

arrester toward the CPE AP and the PoE injector.

2. For secured reason, while install the CPE AP, please be aware for

the electric wires around, and tighten the pole. Without tighten

the CPE AP, the pole and the installed site is with electric wire

around, there could be danger of being hurt by falling or lethal

injury.

4. Connect the 12V 1.25A DC power adapter to the PoE Injector socket, and plug it

into an AC outlet to power on the WNAP-7200.

Note

1. The PoE Injector is a passive device. It will inject the DC power

into the UTP cable right away once you connect the DC-plug in to

the DC-jack of the PoE Injector.

2. DONOT connect the PoE Injector labeled as POE port to any

devices but WNAP-7200, otherwise it will damage the device

permanently.

5. For Ethernet port application, please refer to user’s manual for bridge, gateway

and WISP application for the rst installation, LAN port is suggested.

Note

1. ONLY use the power adapter supplied with the WNAP-7200.

Otherwise, the product may be damaged.

2. Strongly suggest using STP cable whether the cable exposed

outdoor for waterproof and avoiding thunder stroke.
