English 15
Note 2
This maintenance cycle indicates recommended
lengths of time until the need arises for maintenance
work, in order to ensure the product is operational
as long as possible.
Use for appropriate maintenance design (budgeting
maintenance and inspection fees, etc.).
Contact your dealer for details.
Note: Breakage due to taking apart or cleaning
inside by anyone other than our authorized dealers
may not be included in the warranty.
■ Moving and discarding the unit
• Contact your dealer for removing and reinstalling
the system air conditioner since they require tech-
nical expertise.
• The system air conditioner uses fluorocarbon
refrigerant.
Contact your dealer for discarding the system air
conditioner since it is required by law to collect,
transport and discard the refrigerant in accor-
dance with relevant local and national regulations.
■ Where to call
For after-sales service, etc., consult with your dealer.
■ Warranty period:
• This product includes a warranty card.
The warranty card is given to a customer after
dealer staff fills out necessary items in the card.
The customer should check the entered items
and store it carefully.
Warranty period: Within one year after
installation.
For further details, refer to
the warranty card.
•
If it is necessary to repair the air conditioner within
the warranty period, contact your dealer and show
your warranty card. If the warranty card is not
shown, pay-service repair may be performed even
though the warranty period is not expired.
01_EN_3P201178-1C.fm Page 15 Wednesday, April 25, 2007 11:41 AM
